NEM 13 mm coil

NEM cartridge valves, to screw into blocks with the brand's standard cavities (08, 10, 12, 16 and 20, 2, 3 or 4-way). Each version in the list gives the cavity, the flow, the pressure range and the NEM code.

Continuous duty coils (100% ED) for NEM solenoid valves with a 13 mm tube: 20.5 W (13 × 37.7 mm), with standard, AMP-Junior or Deutsch DT04 plug, or 22 W (13 × 38.5 mm), at 12 or 24 V DC.
