Accumulator clamps, jaws and brackets

Parts to fix the accumulator to the machine or to the power pack frame, so that it does not work loose under vibration and the weight of the oil.

• Clamps (straps) for WA and LA diaphragm accumulators: 97-105 mm (WA 0.35-0.5 L), 115-123 mm (WA 0.75-1 L and LA 0.75-1.5 L), 141-154 mm (WA 1.4 L) and 168-181 mm (WA 3 L)
• Jaws for SI and LALS accumulators: 122-144 mm (SI 1-2 L, LALS 1 L), 168-176 mm (SI 4-10 L) and 215-227 mm (SI 10-55 L)
• Brackets for SI accumulators of 4, 6 and 10 L and from 10 to 55 L

The range given in each option is the outside diameter of the shell that the part clamps. Measure the accumulator diameter before choosing: the volume is a guide, but accumulators of another series with the same volume may have a different diameter.
