Argo-Hytos sequence valve (cartridge)

Name: Argo-Hytos sequence valve (cartridge)
Brand: Argo Hytos
Availability: InStock

€106.26

Tax included Delivery in 1 to 5 working days.

(86.39 € No tax)

Argo-Hytos cartridge sequence valves: spool-type SS4A-A3 (10-50 and 50-240 bar) and poppet-type SS3A-BP3 (70-210 and 140-420 bar).

Sequence valve: SS3A-BP3/H21S-B 70-210BAR

Quantity

In stock

Are you an OEM? Reseller? Workshop?

Get special conditions

Ref. AH.44944200

€86.39 excl. VAT

Request a commercial proposal

Delivery in 1 to 5 working days in mainland Portugal (items in stock); Spain 3 working days, rest of the EU 5 working days. Times are estimates.

Shipping from €6.15 in Portugal, €7.38 in Spain and €24.60 in the rest of the EU; free from €100 + VAT in mainland Portugal, €150 + VAT in Spain and €400 + VAT in the rest of the EU. You can also collect from our shop in Leiria.

Returns within 14 days, by post.

Payment by Multibanco, MB WAY, card, Apple Pay, Google Pay or bank transfer.

Shipping costs

Argo-Hytos direct-acting sequence cartridges, to screw into a manifold. They keep the passage to the secondary circuit closed until the inlet pressure reaches the set value; at that point they open and feed the next actuator.

SS4A-A3 (3/4-16 UNF thread): spool type, internal pilot and drain, up to 30 l/min and 350 bar; 10-50 bar and 50-240 bar versions. Back pressure at the tank port adds to the setting. Adjusted with an Allen key
SS3A-BP3 (7/8-14 UNF thread, 10-3S cavity): poppet type, external drain, up to 40 l/min; 70-210 bar and 140-420 bar versions. It has a built-in check valve from 2 to 1, and back pressure at port 2 does not change the opening; port 3 must be kept unpressurised

The two families use different cavities and are not interchangeable. Check the manifold cavity and the pressure range before ordering.

Source: Argo-Hytos SS4A-A3 technical data sheet, HA 5049, 02/2016; Argo-Hytos SS3A-BP3 technical data sheet, HA 5047, 11/2022.
