Aircomp G1/2 pressure regulator Line 075 with gauge

Aircomp pressure regulator from the 075 modular line, with G1/2 thread and pressure gauge. The rolling diaphragm keeps the set pressure steady even when the network pressure varies, and the built-in relieving quickly releases downstream overpressure.

• Maximum inlet pressure: 12.5 bar
• Reference flow: 2880 Nl/min (at 6.3 bar, Δp 1 bar)
• Maximum ambient temperature: 50 °C (at 10 bar)
• Knob with regulation lock; wall mounting through the holes in the body or with a bracket

In Line 075 the regulator is made with 0-4, 0-8 or 0-12.5 bar ranges. Our reference is incomplete and does not show the range of this unit: if you need a specific range, ask us to confirm it before ordering.

Source: Aircomp air preparation units technical catalogue.
