Pressure gauge bottom connection DN100

100 mm diameter pressure gauge with bottom (vertical) connection: the 1/2" thread comes out under the case, for direct mounting on a manifold, a power unit or a test bench, with the dial upright. The large dial allows an accurate reading, also from a distance.

There are 13 scales, from 0-10 to 0-1600 bar (10, 16, 25, 40, 60, 100, 160, 250, 315, 400, 600, 1000 and 1600 bar), from pilot pressures up to the very high pressure circuits of cylinders and tools.

Choose a scale above the maximum circuit pressure and check that the test point has a 1/2" thread; if it is smaller, you will need an adapter.
