  • Aircomp 1252136003 5/3 pressurised centre G1/4 solenoid valve, line 125

Aircomp 1252136003 5/3 pressurised centre G1/4 solenoid valve, line 125

€49.14
Price including VAT at the legal rate Delivery in 1 to 5 working days.

(39.95 € Excluding VAT. VAT at the legal rate applies.)

Aircomp line 125 5/3 pressurised centre pneumatic solenoid valve, with G1/4 ports and spring centring. End-of-stock item.

Quantity
Last items in stock

Are you an OEM? Reseller? Workshop?

Get special conditions

Ref. 1252136003

€39.95 excl. VAT

Request a commercial proposal

Delivery in 1 to 5 working days in mainland Portugal (items in stock); Spain 3 working days, rest of the EU 5 working days. Times are estimates.

Shipping from €6.15 in Portugal, €7.38 in Spain and €24.60 in the rest of the EU; free from €100 + VAT in mainland Portugal, €150 + VAT in Spain and €400 + VAT in the rest of the EU. You can also collect from our shop in Leiria.

Returns within 14 days, by post.

Payment by Multibanco, MB WAY, card, Apple Pay, Google Pay or bank transfer.

Shipping costs

5-way, 3-position solenoid valve, with a solenoid on each side and pressurised centre position (EVR 1/4" 22 6 SL RC CP P in the Aircomp catalogue). With both coils de-energised, the springs centre the spool and the supply passes to both outlets, 2 and 4, with the exhausts closed.

  • Ports 1, 2 and 4: G1/4; exhausts 3 and 5: G1/8
  • Working pressure: 2 to 10 bar
  • 22 mm coils, sold separately: 24 V DC, 24 V AC, 110 V or 220 V AC
  • Weight: 0.136 kg

On a single-rod cylinder, a pressurised centre tends to extend the rod; please check this is the function you need.

Source: Aircomp Valves technical catalogue.
