Duplomatic VD3-W1/30 in-line check valve 3/8"

* Price on request *

Tax included

Duplomatic VD3-W1/30 in-line check valve, 3/8" BSP threads, cracking at 0.35 bar.

Quantity

Sold out - Contact us at info@hidraulica.pt

Are you an OEM? Reseller? Workshop?

Get special conditions

Ref. D.VD3W130

Request a commercial proposal

Delivery in 1 to 5 working days in mainland Portugal (items in stock); Spain 3 working days, rest of the EU 5 working days. Times are estimates.

Shipping from €6.15 in Portugal, €7.38 in Spain and €24.60 in the rest of the EU; free from €100 + VAT in mainland Portugal, €150 + VAT in Spain and €400 + VAT in the rest of the EU. You can also collect from our shop in Leiria.

Returns within 14 days, by post.

Payment by Multibanco, MB WAY, card, Apple Pay, Google Pay or bank transfer.

Shipping costs

The VD3-W1/30 is a Duplomatic check valve for in-line mounting, with BSP (G 3/8") threads on both ends. It lets oil flow freely from A to B and blocks the opposite direction. The poppet is held closed by a spring and opens when the pressure at A exceeds the spring setting plus any pressure at B.

Size: 3/8" BSP (VD3)
Cracking pressure: 0.35 bar (W1)
Maximum flow: 40 l/min
Maximum pressure: 400 bar
Series 30; weight 0.26 kg

For HL or HM mineral oil. Fit the valve with inlet A on the side the oil comes from.

Source: Duplomatic VD*-W* technical catalogue, version 45 200/110 ED.
