Marchesini BS030 / BS050 CETOP subplate with relief valve

Name: Marchesini BS030 / BS050 CETOP subplate with relief valve
Availability: InStock

€71.52

Price including VAT at the legal rate Delivery in 1 to 5 working days.

(58.15 € Excluding VAT. VAT at the legal rate applies.)

Marchesini subplates with built-in pressure relief valve, for one NG6 (CETOP 3) or NG10 (CETOP 5) valve.

CETOP subplate: NG6 3/8" - BS030/220

Quantity

In stock

Are you an OEM? Reseller? Workshop?

Get special conditions

Ref. 1.MA21.BS30220

€58.15 excl. VAT

Request a commercial proposal

Delivery in 1 to 5 working days in mainland Portugal (items in stock); Spain 3 working days, rest of the EU 5 working days. Times are estimates.

Shipping from €6.15 in Portugal, €7.38 in Spain and €24.60 in the rest of the EU; free from €100 + VAT in mainland Portugal, €150 + VAT in Spain and €400 + VAT in the rest of the EU. You can also collect from our shop in Leiria.

Returns within 14 days, by post.

Payment by Multibanco, MB WAY, card, Apple Pay, Google Pay or bank transfer.

Shipping costs

Marchesini subplates to mount one NG6 (CETOP 3) or NG10 (CETOP 5) valve, with a pressure relief valve already built in. They make a simple circuit with a single solenoid valve possible, without a separate manifold.

BS030 (NG6, 3/8"): up to 40 l/min; BS030/220 adjusts from 20 to 220 bar and BS030/300 from 80 to 300 bar
BS050 (NG10, 3/4"): up to 80 l/min; BS050/120 adjusts from 10 to 120 bar and BS050/300 from 50 to 300 bar
Maximum pressure: 300 bar

Choose the relief valve range by the working pressure of the circuit: a narrower range gives finer adjustment.

Source: Oleodinamica Marchesini Valvole equilibratrici technical catalogue, edition 04.2017.

Reference 1.MA21.BS30220

Data sheet
