Danfoss PVG32 spools
search
  • Danfoss PVG32 spools

Danfoss PVG32 spools

* Price on request *
Tax included

Danfoss spools for the PVB sections of the PVG 32, from 10 to 130 l/min: closed or open centre, with LS a/b, for hydraulic actuation and for friction detent.

Spool: Spool 25 litres for PVG 32 friction (0157.B9701)
Quantity
Product available with different options

Are you an OEM? Reseller? Workshop?

Get special conditions

Ref. 1.0157.B9701

Request a commercial proposal

Delivery in 1 to 5 working days in mainland Portugal (items in stock); Spain 3 working days, rest of the EU 5 working days. Times are estimates.

Shipping from €6.15 in Portugal, €7.38 in Spain and €24.60 in the rest of the EU; free from €100 + VAT in mainland Portugal, €150 + VAT in Spain and €400 + VAT in the rest of the EU. You can also collect from our shop in Leiria.

Returns within 14 days, by post.

Payment by Multibanco, MB WAY, card, Apple Pay, Google Pay or bank transfer.

Shipping costs

Danfoss spools for the PVB sections of PVG 32 proportional directional valves. The spool sets the maximum flow of each port and how the section behaves in the neutral position.

Versions of 10, 25, 40, 65, 100 and 130 l/min are available, in several types:

  • standard (157B7000 to 157B7006) and open centre (157B7100 to 157B7106);
  • with LS a/b, for sections with LSA/B valves (157B7020 to 157B7024);
  • for load holding valves (157B7011 to 157B7013);
  • for PVH hydraulic actuation (157B9000 series);
  • for PVMR friction detent control (157B9700 series), closed centre, open centre or with LS a/b;
  • special PVBS and PVSK spools, identified by code.

To choose, use the code of the old spool or the valve's parts list. Check the flow, the centre type and the section's actuation.

Source: Danfoss PVG 32 technical catalogue, version BC00000038en-US0710, March 2016.

1.0157.B9701

4 other products in the same category:

Viewed products

Are you an OEM? Reseller? Workshop?

Get special conditions

All options for this item (46)

Prices include VAT at the legal rate

Description
Part number
Availability
Price
Spool 25 litres for PVG 32 friction (0157.B9701)
1.0157.B9701
On request
Spool 25 litres for PVG 32 friction with LS a/b (0157.B9721)
1.0157.B9721
On request
Spool 40 litres for PVG32 PVBS-QCS (C) 4/3 A,B,T with open LS (0157.B7122)
1.0157.B7122
On request
Spool 40 litres for PVG32 mixed FC/PC 4/3 AB-C PC-B (0157.B7052)
1.0157.B7052
Last units
€110.42
Spool 40 litres for PVG 32 friction (0157.B9702)
1.0157.B9702
On request
Spool 40 litres for PVG 32 friction with LS a/b (0157.B9722)
1.0157.B9722
Last units
€187.46
Spool 40 litres (157B7062) (0157.B7062)
1.0157.B7062
On request
Spool 60 litres for PVG32 PVBS-QCS (D) 4/3 A,B,T with open LS (0157.B7123)
1.0157.B7123
On request
Spool 65 litres for PVG 32 friction (open centre) (0157.B9713)
1.0157.B9713
Last units
€149.75
Spool 65 litres for PVG 32 friction with LS a/b (0157.B9723)
1.0157.B9723
On request
Spool 65 litres for PVG 32 friction (0157.B9703)
1.0157.B9703
Last units
€99.85
Spool 65 litres PVBS for PVG 32 (0157.B9103)
1.0157.B9103
On request
Spool 65TS (157B7063) (0157.B7063)
1.0157.B7063
On request
Spool 100 litres for PVG32 PVBS-QCS (E) 4/3 A,B,T with open LS (0157.B7124)
1.0157.B7124
On request
Spool 100 litres for PVG 32 friction (0157.B9704)
1.0157.B9704
Last units
€162.69
Spool 100 litres for PVG 32 friction (open centre) (0157.B9714)
1.0157.B9714
On request
Spool 100 litres for PVG 32 friction with LS a/b (0157.B9724)
1.0157.B9724
On request
Open spool A/10 litres for PVG32 (0157.B7100)
1.0157.B7100
On request
Open spool B/40 litres for PVG32 (0157.B7102)
1.0157.B7102
On request
Open spool C/65 litres for PVG32 (0157.B7103)
1.0157.B7103
On request
Open spool F/130 litres for PVG32 (0157.B7106)
1.0157.B7106
On request
Spool B/10 litres for PVG32 (0157.B7000)
1.0157.B7000
Last units
€61.86
Spool B/25 litres for PVG32 (0157.B7001)
1.0157.B7001
In stock
€83.77
Spool C/25 litres PC-AB for PVG32 for load holding valve (0157.B7011)
1.0157.B7011
Last units
€80.80
Spool C/40 litres for PVG32 (0157.B7002)
1.0157.B7002
Last units
€68.80
Spool C/40 litres PC-AB for PVG32 for load holding valve (0157.B7012)
1.0157.B7012
Last units
€108.66
Spool C/65 litres PC-AB for PVG32 for load holding valve (0157.B7013)
1.0157.B7013
Last units
€80.80
Spool D/10 litres for PVG32 with LS a/b (0157.B7020)
1.0157.B7020
On request
Spool D/10 litres for PVG32 hydraulic control (0157.B9000)
1.0157.B9000
On request
Spool D/25 litres for PVG32 with LS a/b (0157.B7021)
1.0157.B7021
Last units
€82.23
Spool D/25 litres for PVG32 hydraulic control (0157.B9001)
1.0157.B9001
On request
Spool D/40 litres LSa/b for PVG32 hydraulic control (0157.B9022)
1.0157.B9022
On request
Spool D/40 litres for PVG32 with LS a/b (0157.B7022)
1.0157.B7022
Last units
€112.41
Spool D/65 litres LSa/b for PVG32 hydraulic control (0157.B9023)
1.0157.B9023
On request
Spool D/65 litres for PVG32 (0157.B7003)
1.0157.B7003
On request
Spool D/65 litres for PVG32 with LS a/b (0157.B7023)
1.0157.B7023
Last units
€104.30
Spool D/65 litres for PVG32 hydraulic control (0157.B9003)
1.0157.B9003
On request
Spool D/100 litres for PVG32 hydraulic control (0157.B9004)
1.0157.B9004
On request
Spool D/130 litres for PVG32 hydraulic control (0157.B9005)
1.0157.B9005
On request
Spool E/100 litres for PVG32 (0157.B7004)
1.0157.B7004
Last units
€77.43
Spool E/100 litres for PVG32 with LS a/b (0157.B7024)
1.0157.B7024
In stock
€80.56
Spool F/130 litres for PVG32 (0157.B7006)
1.0157.B7006
On request
PVBS spool (157B7074) (0157.B7074)
1.0157.B7074
On request
PVBS spool (157B7524) (0157.B7524)
1.0157.B7524
On request
Spool PVSK32-SPOOL-CC-25L-HPCO-PVML (157B9561) (0157.B9561)
1.0157.B9561
On request
Spool PVSK32-SPOOL-OC-40L-HPCO-PVML (157B9560) (0157.B9560)
1.0157.B9560
On request
