DIN cutting ring for lubrication (LL series)

Name: DIN cutting ring for lubrication (LL series)
Brand: VOSS
Availability: InStock

€0.93

Tax included Delivery in 1 to 5 working days.

(0.76 € No tax)

DIN cutting ring from the LL (extra-light) series for 6, 8, 10 and 12 mm lubrication pipes.

Lubrication accessory: 10LL

Quantity

In stock

Are you an OEM? Reseller? Workshop?

Get special conditions

Ref. 1.5917.LL10

€0.76 excl. VAT

Request a commercial proposal

Delivery in 1 to 5 working days in mainland Portugal (items in stock); Spain 3 working days, rest of the EU 5 working days. Times are estimates.

Shipping from €6.15 in Portugal, €7.38 in Spain and €24.60 in the rest of the EU; free from €100 + VAT in mainland Portugal, €150 + VAT in Spain and €400 + VAT in the rest of the EU. You can also collect from our shop in Leiria.

Returns within 14 days, by post.

Payment by Multibanco, MB WAY, card, Apple Pay, Google Pay or bank transfer.

Shipping costs

Cutting ring from the LL series, the extra-light series of DIN cutting-ring fittings, for 6, 8, 10 or 12 mm OD steel pipe. It is the series used on centralised lubrication lines and other small low-pressure lines.

It is fitted on the pipe with the LL series DIN nut: when the nut is tightened on the fitting, the ring bites into the pipe and makes the seal. In the attached VOSS datasheet, the LL rings (type 1S) from 4 to 8 mm are rated PN 100.

The option size is the outside diameter of the pipe. Check it with a calliper and always use a new ring when the pipe is cut again.

Source: VOSS 1S and VOSS Ring M cutting rings datasheet.
