Oil level gauge with thermometer 127 mm FL2

Name: Oil level gauge with thermometer 127 mm FL2
Brand: Miselli
Availability: InStock

€27.00

Tax included Delivery in 1 to 5 working days.

(21.95 € No tax)

Miselli FL2 127 mm oil level gauge with thermometer, in transparent polyamide.

Level gauge: 127 - M10

Quantity

In stock

Are you an OEM? Reseller? Workshop?

Get special conditions

Ref. 1.2060.127TM10

€21.95 excl. VAT

Request a commercial proposal

Delivery in 1 to 5 working days in mainland Portugal (items in stock); Spain 3 working days, rest of the EU 5 working days. Times are estimates.

Shipping from €6.15 in Portugal, €7.38 in Spain and €24.60 in the rest of the EU; free from €100 + VAT in mainland Portugal, €150 + VAT in Spain and €400 + VAT in the rest of the EU. You can also collect from our shop in Leiria.

Returns within 14 days, by post.

Payment by Multibanco, MB WAY, card, Apple Pay, Google Pay or bank transfer.

Shipping costs

Oil level gauge with thermometer for the tank wall, with 127 mm between the fixing holes. It is used on power unit and machine tanks where the level and temperature need to be seen without opening anything.

Transparent polyamide body, with a black painted steel guard and a white screen marked with minimum and maximum levels. The hollow bolts seal with an NBR O-ring and flat washer.

Bolts: M10 or M12, depending on the option
Mounting from outside into threaded holes, or from inside with the flanged nuts included
Maximum recommended tightening torque: 5 Nm
Maximum working temperature, according to the manufacturer: 100 °C (tested up to 1 bar)

Avoid alcohol-based fluids, hot antifreeze and water above 80 °C, which attack the polyamide.

Source: Miselli Accessories for Hydraulic Components technical catalogue, 2017.
