Duplomatic EWM-P-AA/20M1 digital card for pressure and force control

* Price on request *

Price including VAT at the legal rate

Digital electronic card for closed-loop pressure or force control, with 0.5 to 2.6 A PWM output and USB connection.

Quantity

Sold out - Contact us at info@hidraulica.pt

Are you an OEM? Reseller? Workshop?

Get special conditions

Ref. D.EWMPAA

Request a commercial proposal

Delivery in 1 to 5 working days in mainland Portugal (items in stock); Spain 3 working days, rest of the EU 5 working days. Times are estimates.

Shipping from €6.15 in Portugal, €7.38 in Spain and €24.60 in the rest of the EU; free from €100 + VAT in mainland Portugal, €150 + VAT in Spain and €400 + VAT in the rest of the EU. You can also collect from our shop in Leiria.

Returns within 14 days, by post.

Payment by Multibanco, MB WAY, card, Apple Pay, Google Pay or bank transfer.

Shipping costs

Duplomatic EWM-P-AA digital electronic card, series 20, for closed-loop control of pressure (or force) in a hydraulic system. It drives proportional pressure valves, reducing or relief, and pressure-controlled pumps, comparing the demanded value with the signal from a pressure transducer.

Supply: 12 to 30 V DC
Command and feedback signal: 4 to 20 mA or 0 to 10 V
PWM output adjustable from 0.5 to 2.6 A, protected against overcurrent and short circuit
Parameter setting via USB with the EWMPC software
DIN rail mounting, IP20, -20 °C to +60 °C

It is installed in the control cabinet, in the 24 V signal area. Before ordering, check the code on the label and the valve to be driven.

Source: Duplomatic EWM-P-AA/20 Digital Card manual, version 89500/115 ETM.
