Hydreco HPV1-C01-SA-015-S-0 hydraulic pilot joystick
search
  • Hydreco HPV1-C01-SA-015-S-0 hydraulic pilot joystick

Hydreco HPV1-C01-SA-015-S-0 hydraulic pilot joystick

€461.94
Tax included

(375.56 € No tax)

Hydreco HPV1 hydraulic pilot control, dual axis with spring return, straight handle without switches and 1/4" BSP ports.

Quantity
Last items in stock

Are you an OEM? Reseller? Workshop?

Get special conditions

Ref. D.HPV1C01SA015S0

€375.56 excl. VAT

Request a commercial proposal

Delivery in 1 to 5 working days in mainland Portugal (items in stock); Spain 3 working days, rest of the EU 5 working days. Times are estimates.

Shipping from €6.15 in Portugal, €7.38 in Spain and €24.60 in the rest of the EU; free from €100 + VAT in mainland Portugal, €150 + VAT in Spain and €400 + VAT in the rest of the EU. You can also collect from our shop in Leiria.

Returns within 14 days, by post.

Payment by Multibanco, MB WAY, card, Apple Pay, Google Pay or bank transfer.

Shipping costs

Hydraulic pilot control valve (joystick) from the Hydreco HPV1 series: with a single dual-axis lever, it sends pilot pressure proportional to the stroke to operate pilot-controlled directional valves. The code decodes as follows, according to the Hydreco catalogue:

  • C01: spring return on both axes
  • SA: straight handle without electric switch
  • 015: metering curve with step, no. 015
  • S: square gaiter
  • 0: standard return spring (1.2 to 2.5 daN)
  • No port code: 1/4" BSP

Maximum pressure 50 bar at inlet P and 3 bar at return T; four service ports (1 to 4). Used on excavators, cranes, forestry machines and access platforms. Before ordering, check the curve and the handle of the joystick fitted.

Source: Hydreco HPV1 technical catalogue, version HPV1_2023_01.
