Duplomatic DSE5 proportional directional valve NG10 (CETOP 5)
€1,234.42
Tax included
Delivery in 1 to 5 working days.
(1003.59 € No tax)
Duplomatic DSE5 proportional directional valve, NG10 (CETOP 5), up to 320 bar, 60 l/min spools and a 75 l/min DSE5J version with on-board electronics.
Duplomatic DSE5 direct-acting proportional directional valve, with ISO 4401-05 interface, NG10 (CETOP 5). It controls the direction and speed of higher-flow cylinders and motors, with the spool opening proportional to the solenoid current.
- Maximum pressure: 320 bar at P, A and B; 210 bar at T in the standard version
- A60 and C60: 60 l/min spools at Δp 10 bar, in two-solenoid or single-solenoid versions (SA, SB)
- C60SB with external drain Y, which allows up to 320 bar on line T
- C75SA: DSE5J version, with on-board electronics (E0K11) and position transducer, 75 l/min
- C60SA with 12 V DC solenoid; the others are 24 V DC
A = open centre, C = closed centre. Check the scheme and voltage on the valve nameplate before ordering.
Source: Duplomatic DSE5 technical catalogue, version 83 260/116 ED; Duplomatic Product Overview Industrial Hydraulics product guide.
D.DSE5A6024
Data sheet
- CETOP interface
- NG10 (CETOP 5)
Specific References
- MPN
- DSE5A6024
4 other products in the same category:
Are you an OEM? Reseller? Workshop?
All options for this item (6)
Description
Part number
Availability
Price
2 proportional solenoids, 3 positions - A60 - DC - 24 V - None
D.DSE5A6024
Last units
2 proportional solenoids, 3 positions - C60 - DC - 24 V - None
D.DSE5C6024
On request
1 proportional solenoid, 2 positions - A60SB - DC - 24 V - None
D.DSE5A60SB24
On request
1 proportional solenoid, 2 positions - C60SA - DC - 12 V - None
D.DSE5C60SA12
On request
1 proportional solenoid, 2 positions - C60SB - DC - 24 V - External drain (Y)
D.DSE5C60SB24Y
On request
1 proportional solenoid, 2 positions - C75SA - DC - 24 V (integrated electronics) - Integrated electronics (E0K11)
D.DSE5JC75SA
On request
No option matches the filters.
Duplomatic DSE5 proportional directional valve, NG10 (CETOP 5), up to 320 bar, 60 l/min spools and a 75 l/min DSE5J version with on-board electronics.
