Aircomp swivel push-in fitting (302.35 series, to be confirmed)

Aircomp central female push-in tee, Line 302

Name: Aircomp central female push-in tee, Line 302
Availability: InStock

€2.68

Price including VAT at the legal rate Delivery in 1 to 5 working days.

(2.18 € Excluding VAT. VAT at the legal rate applies.)

Aircomp 302.35 push-in tee with G female thread on the central branch, for Ø4 to Ø12 mm tube. End-of-stock item.

Thread: G1/4

Tube: Ø10 mm

Quantity

In stock

Are you an OEM? Reseller? Workshop?

Get special conditions

Ref. 302351014

€2.18 excl. VAT (VAT added at the legal rate)

Request a commercial proposal

Delivery in 1 to 5 working days in mainland Portugal (items in stock); Spain 3 working days, rest of the EU 5 working days. Times are estimates.

Shipping from €6.15 in Portugal, €7.38 in Spain and €24.60 in the rest of the EU; free from €123 incl. VAT in mainland Portugal, €184.50 incl. VAT in Spain and €492 incl. VAT in the rest of the EU. You can also collect from our shop in Leiria.

Returns within 14 days, by post.

Payment by Multibanco, MB WAY, card, Apple Pay, Google Pay or bank transfer.

Shipping costs

Aircomp tee, series 302.35 (Line 302, parallel thread): two in-line push-in connections for the tube and a G female thread on the central branch. It lets you take a branch off a tube line to a gauge, pressure switch or other male-threaded accessory.

For compressed air and vacuum (down to -750 mmHg); not for other gases or liquids
Working pressure: 0 to 16 bar
Temperature: -20 to 80 °C
Recommended tube: nylon or polyurethane

Sizes (tube and thread): Ø4 mm with G1/8; Ø8 mm with G1/8 or G1/4; Ø10 mm with G1/4 or G3/8; Ø12 mm with G1/4, G3/8 or G1/2.

Both tube ends have the same diameter; to join tubes of different sizes, use a reducing union.

Source: Aircomp Raccordi technical catalogue, version 2.0, April 2011.
