Marchesini VF-NC push-button end-of-stroke valve

Name: Marchesini VF-NC push-button end-of-stroke valve
Brand: Oleodinamica Marchesini
Availability: InStock

€101.84

Price including VAT at the legal rate Delivery in 1 to 5 working days.

(82.8 € Excluding VAT. VAT at the legal rate applies.)

Marchesini VF push-button end-of-stroke valve, normally closed, 3/8" to 3/4": it opens the passage when the plunger is pushed in.

End-of-stroke valves: 3/8" - V0827

Quantity

In stock

Are you an OEM? Reseller? Workshop?

Get special conditions

Ref. 1.MA11.V0827

€82.80 excl. VAT

Request a commercial proposal

Delivery in 1 to 5 working days in mainland Portugal (items in stock); Spain 3 working days, rest of the EU 5 working days. Times are estimates.

Shipping from €6.15 in Portugal, €7.38 in Spain and €24.60 in the rest of the EU; free from €100 + VAT in mainland Portugal, €150 + VAT in Spain and €400 + VAT in the rest of the EU. You can also collect from our shop in Leiria.

Returns within 14 days, by post.

Payment by Multibanco, MB WAY, card, Apple Pay, Google Pay or bank transfer.

Shipping costs

Technical guide: How to choose a hydraulic valve: types, mounting, coils and flow

Push-button end-of-stroke valve, normally closed, with leak-free ball seat: at rest the passage is closed; when the plunger is pushed in, oil flows from P to A. It is used to sequence two actuators or as an end-of-stroke valve with port A connected directly to tank.

Codes: V0827 (V-101 3/8" NC, 40 l/min), V0828 (V-121 1/2" NC, 60 l/min) and V0829 (V-201 3/4" NC, 100 l/min)
Maximum pressure: 350 bar
Maximum plunger stroke: 13 mm, with immediate opening
Zinc-plated steel body, hardened and ground steel internals, NBR seals

Usual connection: P to the working line and A to tank; the circuit may vary with the function. The Marchesini catalogue is in the attachments.

Source: Oleodinamica Marchesini technical catalogue, section 13 End stroke valves, 2008.
