Duplomatic DSE2 proportional directional valve NG4 (CETOP 2)

€726.47
Tax included

(590.63 € No tax)

Duplomatic DSE2 direct-acting proportional directional valve, NG4 (CETOP 2), up to 350 bar and 20 l/min.

Operation: 2 proportional solenoids, 3 positions
Spool: A01
Current: DC
Voltage: 12 V
Extras: None
Quantity
Last items in stock

Are you an OEM? Reseller? Workshop?

Get special conditions

Ref. D.DSE2A01D12

€590.63 excl. VAT

Request a commercial proposal

Delivery in 1 to 5 working days in mainland Portugal (items in stock); Spain 3 working days, rest of the EU 5 working days. Times are estimates.

Shipping from €6.15 in Portugal, €7.38 in Spain and €24.60 in the rest of the EU; free from €100 + VAT in mainland Portugal, €150 + VAT in Spain and €400 + VAT in the rest of the EU. You can also collect from our shop in Leiria.

Returns within 14 days, by post.

Payment by Multibanco, MB WAY, card, Apple Pay, Google Pay or bank transfer.

Shipping costs

Duplomatic DSE2 direct-acting proportional directional valve, with ISO 4401-02 interface, NG4 (CETOP 2). It controls the direction and speed of small cylinders and motors: the spool opening follows the solenoid current. It is driven by an external electronic card or a controlled current supply.

According to Duplomatic, it works up to 350 bar and 20 l/min, which suits compact, low-flow circuits.

The available option has two proportional solenoids and three positions, scheme A01, with 12 V DC solenoids. Before ordering, check the scheme and voltage on the nameplate of the fitted valve.

Source: Duplomatic Product Overview Industrial Hydraulics product guide.

D.DSE2A01D12
