Female-male ORFS-BSP adapter

Name: Female-male ORFS-BSP adapter
Brand: FOR
Availability: InStock

€13.55

Price including VAT at the legal rate Delivery in 1 to 5 working days.

(11.02 € Excluding VAT. VAT at the legal rate applies.)

Adapter with a female ORFS nut and a male BSP end, to connect a male ORFS end to a BSP port. ORFS from 9/16" to 1.11/16" and BSP from 1/4" to 1.1/4".

ORFS accessory: 11/16" - 1/2"

Quantity

In stock

Are you an OEM? Reseller? Workshop?

Get special conditions

Ref. 1.0947.111612

€11.02 excl. VAT

Request a commercial proposal

Delivery in 1 to 5 working days in mainland Portugal (items in stock); Spain 3 working days, rest of the EU 5 working days. Times are estimates.

Shipping from €6.15 in Portugal, €7.38 in Spain and €24.60 in the rest of the EU; free from €100 + VAT in mainland Portugal, €150 + VAT in Spain and €400 + VAT in the rest of the EU. You can also collect from our shop in Leiria.

Returns within 14 days, by post.

Payment by Multibanco, MB WAY, card, Apple Pay, Google Pay or bank transfer.

Shipping costs

Straight adapter with a female ORFS nut on one side and a male BSP end on the other. The male BSP end screws into the port of the pump, manifold or valve, and the ORFS nut tightens onto a male ORFS end, such as that of a hose fitting or another adapter.

An ORFS connection seals with an O-ring seated in the flat face of the male, pressed against the face of the female part. When fitting, check that the O-ring is in place and in good condition.

There are 14 combinations, with ORFS from 9/16" to 1.11/16" and BSP from 1/4" to 1.1/4". In the option list the first size is the ORFS and the second the BSP.

To identify the ORFS size, measure the outside diameter of the male thread: about 14.3 mm for 9/16", 17.5 mm for 11/16", 20.6 mm for 13/16", 25.4 mm for 1" and 30.2 mm for 1.3/16".
