Duplomatic QDE3 proportional flow control valve NG6 (CETOP 3)
* Preço sob consulta *
Price including VAT at the legal rate
Duplomatic QDE3 pressure-compensated proportional flow control valve, NG6 (CETOP 3), up to 250 bar, ranges of 14, 30 and 40 l/min.
Duplomatic QDE3 direct-acting, pressure-compensated proportional flow control valve, with ISO 6263-03 (CETOP 03) interface. It regulates the flow in a branch of the circuit or the speed of a cylinder according to the solenoid current; the pressure compensator keeps the set flow steady even when the load changes.
It can work as a two-way or three-way valve, depending on whether port P is used. Maximum pressure 250 bar.
- QDE3-14: up to 14 l/min
- QDE3-30: up to 30 l/min
- QDE3-40: up to 40 l/min
All with 24 V DC solenoid and DIN 43650 plug. The manufacturer specifies a minimum inlet flow of 40 l/min for the 14 and 30 l/min ranges and 50 l/min for the 40 l/min range.
Source: Duplomatic QDE* technical catalogue, version 82 220/112 ED.
D.QDE31424
Data sheet
- CETOP interface
- NG6 (CETOP 3)
4 other products in the same category:
Are you an OEM? Reseller? Workshop?
All options for this item (3)
Description
Part number
Availability
Price
QDE3-14/10N-D24K1
D.QDE31424
On request
QDE3-30/10N-D24K1
D.QDE33024
On request
QDE3-40/10N-D24K1
D.QDE34024
Last units
€854.69
No option matches the filters.
Duplomatic QDE3 pressure-compensated proportional flow control valve, NG6 (CETOP 3), up to 250 bar, ranges of 14, 30 and 40 l/min.
